Product Description
MORE OUTPUT AND DYNAMIC RANGE
Outperforms normal spec pickups by providing extra output and excellent touch sensitivity
STINGRAY HT NECK PICKUP
The custom-wound neck humbucker also features a large ceramic magnet and has been wound specifically to pair with the Stingray's HT bridge pickup.
STINGRAY HT BRIDGE PICKUP
The Stingray HT (Heat Treated) bridge pickup outperforms normal spec pickups with more output, dynamic range, and excellent touch sensitivity. The pickup not only achieves ultra-high output but also garners a powerful low-end response while retaining a distinctively clean, clear tone and definition at lower volume levels.
STRONGER LOW END AND EXTENDED FREQUENCY RESPONSE
HT pickups display a more powerful bass response and expansion of higher frequency harmonics
PUSH PUSH BOOST CIRCUIT
The Stingray HT preamp boost is activated by a push-push volume knob and is factory set to 12db. Via a trim pot inside the control cavity, the preamp can be adjusted up to 20db if needed for heavy rhythm parts or high octane soloing whenever the user chooses.
TRANSPARENT BUFFERED OUTPUT
No matter where your volume control is set, the transparent buffered output preserves your signal from high-frequency loss and keeps your tone bright and strong.
TUNE-O-MATIC BRIDGE
In use since the early 1950s, this popular bridge option is standard on the new Stingray HT. The Tune-o-Matic bridge is great for players who prefer a hardtail bridge option with great sustain and ease of string replacement.
| Specifications | StingRay HT |
|---|---|
| Model | StingRay HT |
| Size | 14-1/16" wide, 1-5/8" thick, 39-1/4" long (35.7 cm wide, 4.1 cm thick, 99.7 cm long) |
| Body Wood | Alder |
| Body Finish | High Gloss Polyester |
| Pickguard | Black/White/Black |
| Scale Length | 25.5" |
| Neck Radius | 10" (25.4 cm) |
| Headstock Size | 6-3/8" (16.2 cm) long |
| Frets | 22 - High Profile, Medium Width, Stainless Steel |
| Neck Width | 1-5/8" (41.3 mm) at nut; 2-1/4" (56.9 mm) at last fret |
| Neck Wood | Roasted Figured Maple |
| Fingerboard | Brulee & Raspberry Burst - Figured Roasted Maple; Midnight Rider - Ebony; Showtime - Rosewood |
| Fret Markers | Dot |
| Neck Finish | Gunstock oil and hand-rubbed special wax blend |
| Neck Colors | Natural |
| Tuning Machines | Schaller M6-IND locking |
| Truss Rod | Adjustable - no component or string removal |
| Neck Attachment | 5 bolt, sculpted neck joint |
| Electronic Shielding | Graphite acrylic resin coated body cavity and aluminum lined pickguard |
| Controls | Volume knob with push/push switch for gain boost, tone knob, 3 way pickup selector switch. |
| Switching | 3-way toggle pickup selector; Push/push volume pot for boost |
| Pickups | Bridge - Music Man® HT Humbucker; Neck - Music Man® Custom Wound Neck Humbucker |
| Left Handed | No |
| Strings | 10p-13p-17p-26w-36w-46w (RPS 10 Slinkys #2240) |
